AMX - 912:
Ahuja AMX-912 Professional Audio Mixer
Features
Professional 9-channel audio mixer designed for live sound, studio, and installation use.
6 mono mic/line inputs and 2 stereo line inputs for flexible connectivity.
Built-in 24-bit digital effects processor with multiple reverb, delay, and echo presets.
USB/SD audio player for MP3 playback and recording convenience.
Each mono channel equipped with 3-band EQ (High, Mid, Low) and independent level controls.
Balanced XLR and ¼” combo inputs with switchable +48V phantom power for condenser microphones.
AUX and EFX sends for monitor mixes and external effects routing.
Balanced XLR master outputs and control room outputs for professional setups.
Rugged and compact metal body ideal for portable and installed PA systems.
Perfect for small to medium live events, worship places, schools, and studios.
Specifications
| Parameter | Details |
|---|---|
| Total Input Channels | 9 (6 Mono Mic/Line + 2 Stereo Line) |
| Microphone Inputs | Balanced XLR / ¼” Combo Jack |
| Stereo Inputs | RCA / ¼” Stereo Inputs |
| Equalizer (Mono Channels) | 3-Band EQ: High (12kHz), Mid (2.5kHz), Low (80Hz) |
| Digital Effects Processor | 24-bit DSP with Preset Effects |
| Built-in Player | USB/SD MP3 Player & Recorder |
| Phantom Power | +48V (Global Switchable) |
| AUX Send | 1 (Pre/Post Selectable) |
| EFX Send | 1 (Post Fader) |
| Main Outputs | Balanced XLR (L/R) |
| Control Room Output | Stereo ¼” Jack |
| Headphone Output | Stereo ¼” Jack with Level Control |
| Frequency Response | 20Hz – 20kHz (±1dB) |
| THD | < 0.1% |
| Power Supply | AC 220–240V, 50/60Hz |
| Dimensions (W×H×D) | 420 × 110 × 360 mm (approx.) |
| Weight | Approx. 6.8 kg |
