MX - 15 :
Ahuja MX-15 Professional Audio Mixer
Features
-
Ultra-compact 3-channel professional audio mixer for small PA systems and personal setups.
-
2 mic/line inputs and 1 stereo input — ideal for microphones, instruments, and playback devices.
-
Each mic channel provided with 2-band EQ (High, Low) and independent level control.
-
Balanced XLR and ¼” jack inputs ensure clean, noise-free signal performance.
-
Master output level control with LED level indication for easy monitoring.
-
Phantom power (+15V) available for condenser microphones.
-
AUX send for external effects or monitor use.
-
Headphone output with dedicated level control.
-
Sturdy, compact metal body — perfect for small meetings, presentations, music practice, and home recording.
Specifications
| Parameter | Details |
|---|---|
| Total Input Channels | 3 (2 Mono Mic/Line + 1 Stereo Line) |
| Microphone Inputs | Balanced XLR / ¼” Jack |
| Stereo Inputs | RCA / ¼” Stereo Inputs |
| Equalizer (Mono Channels) | 2-Band EQ (High 10kHz, Low 100Hz) |
| AUX Send | 1 |
| Phantom Power | +15V DC (Switchable) |
| Main Outputs | ¼” Jack (L/R) |
| Headphone Output | ¼” Stereo Jack |
| Frequency Response | 20Hz – 20kHz (±1dB) |
| THD | < 0.1% |
| Power Supply | AC 220–240V, 50/60Hz |
| Dimensions (W×H×D) | 220 × 70 × 180 mm (approx.) |
| Weight | Approx. 2.2 kg |
