TZA - 2000 DP :
Ahuja TZA-2000DP High Power PA Mixer Amplifier
Features
200 Watts RMS PA mixer amplifier ideal for auditoriums, halls, and outdoor applications.
Built-in digital media player with USB, SD/MMC card reader, Bluetooth, and FM tuner.
Six microphone inputs and two auxiliary inputs for maximum flexibility.
Balanced line input and output provided for connecting to external equipment.
Bass and Treble controls for tonal adjustment.
LED-based output level indicator for easy monitoring.
Short circuit, overload, and thermal protection for reliable operation.
Operates on AC mains or 24V DC (Car Battery Operation).
Rugged construction and efficient cooling ensure consistent long-term performance.
Specifications
| Parameter | Details |
|---|---|
| Power Output | 300W Max / 200W RMS |
| Output Regulation | ≤ 2 dB (no load to full load at 1kHz) |
| Input Channels | 6 × Mic (0.65mV / 4.7kΩ) 2 × Aux (100mV / 470kΩ) |
| Frequency Response | 50Hz – 15kHz (±3dB) |
| Signal-to-Noise Ratio | ≥ 60dB |
| Tone Controls | Bass: ±10dB @ 100Hz Treble: ±10dB @ 10kHz |
| Line Output | 1V / 1kΩ |
| Speaker Outputs | 4Ω, 8Ω, 70V & 100V |
| Power Supply | AC 220–240V, 50/60Hz or 24V DC |
| Power Consumption | Approx. 450VA |
| Dimensions (W×H×D) | 483 × 192 × 456 mm |
| Weight | Approx. 22 kg |
